Wooden Go-Kart
Summer 2020 - Fall 2021
When I was 11 years old my brothers and I assembled a motor bike (first picture). We rode it a lot and also tried making all sorts of trailers for it (first picture). Later, we made a wooden go-kart with brakes. After getting it to work, I put on brakes, lights, horn, and steering with a steering wheel instead of steering with feet.
-
This was an early example of a kart we made to get towed by the motor bike. I was in the kart and my brother was riding the motor bike.
-
This is another cart we designed. We put our dog in it too.
-
This handle is the wheel brake we made.
-
This is another angle of the wheel brake.
-
This was the start of the wooden go kart.
-
-
Our dog, Petrica, is happy to be there.
-
My brother was testing the steering.
-
We were testing the kart here.
-
The following pictures go through the building process.
-
-
-
-
This is me drilling in the holes for the brake handle.
-
The brake handles. My little brother is in the background. He was taking a break from playing soccer.
-
This is me hammering in the brake handle.
-
This is my little brother testing it out.
-
This is me working on doing the wiring for the lights.
-
The lights I wired work!
-
-
-
I even put some under glow on it.
-
This is all the wiring I did.
-
This was working on the wiring for the horn. I used a car air horn and wired up a power tool batter with some switches.
-
-
-
This is were I put the switches for the horn. It worked - it was very loud!
-
This picture and the following are the steering mechanism I created to use a steering wheel.
-
-
-
The steering wheel isn't attached. It would go at the top of the steering column. This is the final iteration of the kart.
